--- a/device/rockchip/rk356x/rk3566_r/rk3566_r.mk+++ b/device/rockchip/rk356x/rk3566_r/rk3566_r.mk@@ -46,4 +46,5 @@ PRODUCT_PROPERTY_OVERRIDES += persist.bt.power.down=true PRODUCT_PROPERTY_OVERRIDES += persist.sys.timezone=Asia/Shanghai PRODUCT_PROPERTY_OVERRIDES += ro.vendor.hdmirotationlock=true #PRODUCT_PROPERTY_OVERRIDES += vendor.hwc.device.primary=HDMI-A-1PRODUCT_PROPERTY_OVERRIDES += vendor.hwc.device.primary=DSI+PRODUCT_PROPERTY_OVERRIDES += persist.sys.def_launherpag=com.mdptech.neuronappandroidhu

&i2c3 {        status = "okay";        //是該設備的標簽，用于在設備樹的其他部分或內核代碼中引用這個設備。表示這個設備在I2C總線上的地址是0x14        gt911@14 {                  //設備型號,通過設備型號去尋找對應的驅動程序                compatible = "goodix,gt9xx";                            //設備物理地址                reg = <0x14>;                //客戶端                //引腳的復用(pinctrl子系統)                pinctrl-names = "default";                //pinctrl-0對應defualt狀態，<&touch_gpio>節點，此節點存放的對應狀態的引腳配置                pinctrl-0 = <&touch_gpio>;                //觸摸屏的中斷GPIO，使用GPIO0的第6引腳(RK_PB6)，觸發類型為低電平觸發                goodix_irq_gpio = <&gpio0 RK_PB6 IRQ_TYPE_LEVEL_LOW>;                  //觸摸屏控制器的GPIO，使用GPIO的第5引腳(RK_PB5)，復位信號為高電平觸發                goodix_rst_gpio = <&gpio0 RK_PB5 GPIO_ACTIVE_HIGH>;                touchscreen-swapped-x-y;                touchscreen-inverted-y;                status = "okay";        };};//編寫pinctrl節點&pinctrl {        //服務端        touch {                touch_gpio: touch-gpio {                        //rockchip,pins屬性代表著引腳的復用關系以及電氣屬性                        rockchip,pins =                        //將GPIO 0中的B6設置為了GPIO功能，RK_FUNC_GPIO是一個宏，設置電氣屬性                                <0 RK_PB6 RK_FUNC_GPIO &pcfg_pull_up>,                                <0 RK_PB5 RK_FUNC_GPIO &pcfg_pull_none>;                };        };};
